9
QUICKSTART
F
B
C
G
E
D
A
3. OVERVIEW AND CONFIGURATION
A - Motorised tailstock: supports the upper part of the measured part can be moved automatically along the calliper according to
the size of the piece through the jog on the touchpad.
B - Part to be measured: for the user to affix the piece to be measured between the stocks.
C - Headstock: supports the bottom part of the measured part.
D - ON/OFF switch: machine main start/stop switch (low voltage)
E - Emergency stop button: Press to stop the machine in the event of a dangerous situation. Pull it out once the danger has been
removed.
F - Reflex click button (on touchpad)
G - Touchpad with Reflex Scan
+
App
