Sym JOYMAX 250 User Manual

12. Cooling System
12-13
Place the thermostat into heated water to check its
operation.
Caution
 Whenever the thermostat and the
thermometer are in contact to the wall of
heated water container, the reading
displayed is incorrect. If the valve of the
thermostat remains open at room
temperature or the valve operation is not
corresponding to the temperature change,
then it must be replaced.
Technical Data
Valve begins to open
82~95℃
Valve stroke
0.05 ~ 3mm
Installation
Install the thermostat.
Install the thermostat cover. (2 bolts)
Refill the coolant and bleed out the air bubble
(Page 12-5).
2 bolts
To this chapter contents

Sym JOYMAX 250 Specifications

General

Displacement	249.4 cc
Fuel System	Electronic Fuel Injection
Cooling System	Liquid cooled
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Seat Height	770 mm
Dry Weight	182 kg
Width	760 mm
Height	1, 420 mm
Wheelbase	1, 550 mm
Engine Type	4-stroke, Single cylinder
Transmission	CVT
Fuel Capacity	12 L
Length	2190 mm
