12. Cooling System
12-12
Thermostat
Please refer to chapter 17 for inspection of thermo
unit.
Removal
Remove the luggage box and body cover.
Drain out the coolant.
Remove the thermostat cover. (2 bolts)
Remove the thermostat.
Inspection
Visually inspect thermostat for any damage.
Thermo sensor
2 bolts
