14. Brake System
14-1
Mechanism Diagram ························ 14-1
Maintenance Description ·················· 14-2
Trouble Diagnosis ··························· 14-3
Disk Brake System Inspection ·········· 14-4
Adding Brake Fluid ·························· 14-5
Brake fluid replacement / Air-bleed·· 14-6
Front Brake Caliper ······················· 14-7
Rear Brake Caliper ························ 14-8
Brake Disk ···································· 14-9
Master Cylinder ····························· 14-9
Mechanism Diagram
Front brake Master cylinder
3.0~4.0kgf-m
Delay valve
Front brake caliper
Rear brake Master cylinder
Rear brake caliper
