13. Body Cover

13-7

Inner Box

Remove

Remove wind screen garnish, wind screen, meter

visor, front cover, meter panel, R/L side cover and

front under spoiler.

Loosen 1 screw from reserve tank stay.

Loosen 1 screw from fuse box and remove it.

Loosen 1 screw from main switch cap and remove

the cap.

Loosen DC power outlet mounting nut, and

remove DC power outlet.

Loosen 1 screw from battery cover and remove it.

Remove the battery negative (-) cable.

Remove the battery positive (+) cable.

Remove the battery.

Reserve tank

1 screw

DC power outlet

1 screw

Positive

Negative
