17. Electrical System
17-16
Replacement headlight bulbs
Remove wind screen garnish, wind screen, meter
visor, front cover.
(Refer chapter 13)
Disconnect the rubber sleeve and the terminal
coupler from the headlight.
Loosen 1 screw from the headlight bulb setting
stay.
Remove setting stay and take out the headlight
bulb.
Replace with new bulb if necessary.
Specification:
Lo-beam bulb 12V 55W (H7)
Hi-beam bulb 12V 55W (H7)
Caution
Never touch the bulb with finger, which will
create a heat point.
Clean the fingerprint left on the bulb with
alcohol.
Installation
Install the bulb of the headlight in reverse order of
removal.
Upon completion of replacement, turn on the main
switch to ensure the headlight works well.
Adjust the beam and distance of the headlight if
necessary.
