1. General Information
1-1
Symbols and Marks ······················· 1-1
General Safety ······························ 1-2
Service Precautions ······················ 1-3
Specifications ······························· 1-9
Torque Values ······························· 1-10
Troubles Diagnosis ······················· 1-12
Lubrication Points ························· 1-16
Symbols and Marks
Symbols and marks are used in this manual to indicate what and where the special service are needed, in
case supplemental information is procedures needed for these symbols and marks, explanations will be
added to the text instead of using the symbols or marks.
Means that serious injury or even death may result if procedures are not
followed.
Means that equipment damages may result if procedures are not followed.
Limits to use SAE 10W-30 API SG class oil. Warranty will not cover the
damage that caused by not apply with the limited engine oil.
(Recommended oil: KING MATE G-3 oil)
King Mate G-3 is recommended.
King Mate gear oil serials are recommended. (Bramax HYPOID GEAR OIL
# 140)
Apply sealant; medium strength sealant should be used unless otherwise
specified.
Replace with a new part before installation.
Use recommended brake fluid DOT3 or WELLRUN brake fluid.
Meaning correct installation.
Meaning wrong installation.
Indication of components.
Indicates position and operation directions
Components assembly directions each other.
Indicates where the bolt installation direction, --- means that bolt cross
through the component (invisibility).
To Next Page
