3
2. CONTROL LOCATION
Rear brake level
Front Wheel And
Rear Wheel(for CBS
model)
Fuel tank cap
Starter switch/ Engine Stop
Switch/ Hazard warning Switch
Exhaust muffler
High& Low beam/Turn
signal/passing/Horn
Switch
Front light/
Position light
Tail/Stop light
Battery
Air Cleaner
Front turn
signal light
Storage box
Side stand
Ignition switch
Front brake level
Main stand
Engine number
VIN number
