LS4278 Product Reference GuideC-4

Interleaved 2 of 5

RSS

RSS variants must be enabled to read the bar codes below (see RSS (Reduced Space Symbology) on page 13-

46).

RSS

10293847560192837465019283746029478450366523

(RSS Expanded Stacked)

1234890hjio9900mnb

(RSS Expanded)

08672345650916

(RSS Limited)

12345678901231
