Appendix C RS-232 To RJ45 Conversion Cables
RS-232 — RJ45 (8-pin)
C-RJ45-DB9F-4, RJ-45 to RS232 (Female, DCE) cable, 4’.
RS-232 — DB9 Female
RJ45 (8-pin)
Pin No.
Signal
1
DCD
2
TxD
3
RxD
4
DSR
5
GND
6
DTR
7
CTS
8
RTS
9
---
DB-9 F
8
Pin No.
Signal
1
DSR
2
RTS
3
GND
4
TxD
5
RxD
6
DCD
7
CTS
8
DTR
RS-232 — RJ45 (8-pin)
C-RJ45-DB9M-4, RJ-45 to RS232 (Male, DTE) cable, 4’.
RS-232 — DB9 Male
RJ45 (8-pin)
Pin No.
Signal
1
DCD
2
RxD
3
TxD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
---
DB-9 M
8
Pin No.
Signal
1
DSR
2
RTS
3
GND
4
TxD
5
RxD
6
DCD
7
CTS
8
DTR
