1.4.1.3.4.1.2 Single-ended

Symbol Min. typical Max. Description Impact

:sub`in`

0V +1V The input voltage between

the input and GND.

Any voltage out of this range causes

saturation to min/max ADC value

V -15V +15V The tolerable input voltage

between the input and

GND.

Any voltage out of this range

damages the analog input’s

circuitry.

R 20.4kΩ Internal input resistance

Error -1% +1% Error in ticks

in,lim

1.4.1.3.4.2 Analog input resistance

1.4.1.3.4.2.1 Differential

1.4.1.3.4.2.2 Single-ended
