1.4.3 On-site installation guide (UL)
Please regard this information when installing the Node.
Installation specifications Node 400 Node 1000 Node 2000
E-File number E506869
Rating in Volt 12-48 V
Rating in Ampere 13.2 A RMS 33 A RMS 66 A RMS
Short circuit current rating 5k A
Maximum Surrounding Air Temperature 40° C
Torque Values for Terminal screws 0.5 - 0.6 Nm (4.4 lbf∙in)
Short circuit rating and fuse type Listed Class T Fuse, rated min. 160Vdc 50A
20kA. (JDDZ/7.E81895)
Temperature rating of field installed conductors
>85°
N/A
1.4.3.1 Branch fuse required
SOMANET servo drives don’t have a fuse on-board, so a branch fuse is required as a protection.
The following fuse has been tested and approved by UL according to the requirements of UL 61800-5-1:
Manufacturer Littelfuse
Product designation JLLN050.T
CCN JDDZ/7
Class T
Cat. No. JLLN, 558
V 300V
V 160V
Interrupt Rating (IR) 20kA (@160Vdc)
I nominal 50A
AC
DC
