Page #58 background imageLoading...
Page #58 background image
technical reference
58
SYNRAD OEM v40 Operator’s Manual Version 4
Controlling laser power
The Controlling laser power section includes subsections:
Control signals
Operating modes
Control signals
Much of the information provided in this section describes the use of a SYNRAD UC-2000 Universal
Laser Controller to provide PWM Command signals to the v40 laser. If using an alternate method of laser
control, thoroughly review this section, Controlling laser power, as well as the following section, User
I/O connections, for an understanding of the signal requirements necessary to control Firestar lasers. For
more information about the UC-2000, please consult the UC-2000 Laser Controller Operator’s Manual.
Tickle pulse
Firestar lasers incorporate a built-in tickle generator, freeing customers from the need to supply tickle
pulses between lasing commands. In cases where a 5 kHz, 1 µs tickle pulse is still sent to the laser via a
UC-2000 or other PWM controller, is ignored until the pulse width exceeds approximately 4 microseconds
(µs), at which point lasing occurs.
Warning
serious
personal
injury
Because of phase dierences, external tickle pulses may combine
with the internally-generated tickle signal causing the LASE LED to
icker during the transition from tickle to lasing. Laser output may
occur if the LASE LED ickers.
Tickle pulses pre-ionize the laser gas to just below the lasing threshold so that a further increase in pulse
width adds enough energy to the plasma to cause laser emission. Tickle pulses cause the laser to respond
predictably and almost instantaneously to PWM Command signals, even when there is considerable delay
(laser o time) between applied Command signals.
Pulse Width Modulation (PWM)
Pulse Width Modulation, or PWM, controls laser power by varying the duty cycle of Firestars RF ampli-
ers, which in turn control the time-averaged RF power applied to the laser. Typically, laser output follows
the PWM input with a rise and fall time constant of ~100 µs; however, the laser cannot precisely follow
PWM input signals if the “On pulse is less than 100 µs in duration. At a constant 50% duty cycle, v-Series
lasers typically reach 90–100% of full optical output when operated at a frequency of 5 kHz and reach
65–80% optical output at 7 kHz. The percentage of optical output increases as duty cycle increases (at
a constant PWM frequency) or as PWM frequency decreases (at a constant duty cycle). Following gure
shows representative v40 optical output waveforms at two dierent PWM frequencies.
