Synrad Firestar V Series - OEM V40 Side Panel (SAB Models)

operation
47
SYNRAD OEM v40 Operator’s Manual Version 4
OEM controls and indicators
OEM v40 side panel (SAB models)
Figure 3-5 OEM v40 side panel controls and indicators
1 DB-9 connector – provides a Shutter Switch input as well as auxiliary +5 and +24 VDC outputs. See
DB-9 connections in the Technical Reference chapter for connection details.
(Air-Cooled v40 OEM Shown)
1
