SYNRAD OEM v40 Operator’s Manual Version 4
Troubleshooting
Table 5-3 Interlock Open condition
LED Indicator LED Status Signal Name Output Signal Status
INT Red Interlock Open Closed
TMP Green Over Temperature Open
RDY O Laser Ready Open
SHT Blue Shutter Open Closed
LASE O Laser Active Open
Table 5-4 Over Temperature condition
LED Indicator LED Status Signal Name Output Signal Status
INT Green Interlock Open Open
TMP Red Over Temperature Closed
RDY O Laser Ready Open
SHT Blue Shutter Open Closed
LASE O Laser Active Open
Table 5-5 Shutter Open condition
LED Indicator LED Status Signal Name User I/O Output Status
INT Green Interlock Open Open
TMP Green Over Temperature Open
RDY Yellow Laser Ready Closed
SHT O Shutter Open Open
LASE O Laser Active Open
