Synrad Firestar OEM v30 reference guide
Agency compliance (cont.)
Table 1 Class 4 safety features
Required by: Provided on
Feature Location/Description CDRH EN60825-1 OEM v30
Keyswitch Rear panel control Yes Yes No
On / Off/Reset Keyswitch controls power to laser electronics.
Key cannot be removed from switch in the “On” position.
Shutter Laser control Yes Yes No
function Functions as a beam attenuator to disable RF driver/laser output
when closed.
PWR (Power) Rear panel indicator (Green) No No Yes
indicator Illuminates green to indicate DC power is applied.
RDY (Ready) Rear panel indicator (Yellow) Yes Yes Yes
indicator Indicates that laser has power applied and is capable of lasing.
LASE Rear panel indicator (Red) Yes Yes Yes
indicator Indicates that Firestar is actively lasing. LASE LED illuminates
when the duty cycle of the Command signal is long enough to
produce laser output.
Five second Firestar circuit element Yes No Yes
delay Disables RF driver/laser output for five seconds after Laser Enable
signal is applied.
Power fail Firestar circuit element Yes Yes No
lockout Disables RF driver/laser output if input power is removed then later
reapplied (AC power failure or remote interlock actuation) while
Keyswitch is in “On” position.
Remote Rear panel connection Yes Yes No
Interlock Disables RF driver/laser output when a remote interlock switch on
an equipment door or panel is opened.
Over Firestar circuit element No No Yes
temperature Temperature shutdown occurs if temperature of the laser tube
protection rises above safe operating limits.
Warning Firestar exterior Yes Yes Yes
labels Labels attached to various external housing locations to
warn personnel of potential laser hazards.
Electromagnetic interference standards
The European Union’s Electromagnetic Compatibility (EMC) Directive, 2004/108/EC, is the sole Directive developed to
address electromagnetic interference (EMI) issues in electronic equipment. In particular, the Directive calls out European
Norm (EN) documents that define the emission and immunity standards for specific product categories. For OEM v30 lasers,
EN 61000-6-4 defines radiated and conducted RF emission limits while EN 61000-6-2 defines immunity requirements for
industrial environments.
SYNRAD’s Firestar OEM v30E lasers have demonstrated performance characteristics that have met or exceeded the require-
ments of EMC Directive 2004/108/EC.
