Synrad Firestar OEM v30 reference guide
Troubleshooting
This section is designed to help isolate Firestar OEM v30 lasers problems to the board level only. Problems on circuit boards
or the laser tube are not within the scope of this guide because they are not user-serviceable assemblies; do not attempt to
repair them. Contact SYNRAD or a SYNRAD Authorized Distributor for repair or replacement information.
Danger
serious
personal
injury
This product emits invisible infrared laser radiation in the 9.3–10.6 µm CO
2
wave-
length band. Direct or diffuse laser radiation can inflict severe corneal injuries and can
seriously burn human or animal tissue. Service personnel troubleshooting Firestar lasers
should be thoroughly trained in laser safety practices and electronic service techniques
before attempting repairs.
Caution
possible
equipment
damage
Attempting repair of a SYNRAD Firestar laser without the express authorization
of SYNRAD, Inc. will void the product warranty. If troubleshooting or service as-
sistance is required, please contact the SYNRAD Service Department.
Status indications
OEM v30 LED indicators in conjunction with Interface A (DB-9) or Interface B (RJ45) outputs provide status information to
the user. Table 8 and Table 9 show OEM v30 output signal and LED indicator states during normal and fault conditions for
DB-9 and RJ45 connectors respectively.
Table 8 Interface A (DB-9) status signals
LED Indicator LED Status DB-9 Signal Name DB-9 Signal Status
Normal Fault Normal Fault
LASE (Red) On Off Lase Indicator High Low
RDY (Yellow) On Off Laser Ready High Low
RDY (Yellow) On Flashes Overtemp Fault Low High
PWR (Green) On Flashes DC Voltage Fault Low High
Table 9 Interface B (RJ45) status signals
LED Indicator LED Status RJ45 Signal Name RJ45 Signal Status
Normal Fault Normal Fault
LASE (Red) On Off — — —
RDY (Yellow) On Off Laser Ok High Low
RDY (Yellow) On Flashes Temperature Ok High Low
PWR (Green) On Flashes Voltage Ok High Low
