Synrad Firestar OEM v30 reference guide
Cooling connections (cont.)
Table 4 Dew point temperatures
Dew Point Temperature Chart °F (°C)
Relative Humidity (%)
20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95
Air Temp
°F (°C)
60 (16) — — — 32 36 39 41 44 46 48 50 52 54 55 57 59
(0) (2) (4) (5) (7) (8) (9) (10) (11) (12) (13) (14) (15)
65 (18) — — 33 37 40 43 46 48 51 53 55 57 59 60 62 64
(1) (3) (4) (6) (8) (9) (11) (12) (13) (14) (15) (16) (17) (18)
70 (21) — 33 37 41 45 48 51 53 56 58 60 62 64 65 67 69
(1) (3) (5) (7) (9) (11) (12) (13) (14) (16) (17) (18) (18) (19) (21)
75 (24) — 37 42 46 49 52 55 58 60 62 65 67 68 70 72 73
(3) (6) (8) (9) (11) (13) (14) (16) (17) (18) (19) (20) (21) (22) (23)
80 (27) 35 41 46 50 54 57 60 62 65 67 69 71 73 75 77 78
(2) (5) (8) (10) (12) (14) (16) (17) (18) (19) (21) (22) (23) (24) (25) (26)
85 (29) 40 45 50 54 58 61 64 67 70 72 74 76 78 80 82 83
(4) (7) (10) (12) (14) (16) (18) (19) (21) (22) (23) (24) (26) (27) (28) (28)
90 (32) 44 50 54 59 62 66 69 72 74 77 79 81 83 85 87 88
(7) (10) (12) (15) (17) (19) (21) (22) (23) (25) (26) (27) (28) (29) (31) (31)
95 (35) 48 54 59 63 67 70 73 76 79 81 84 86 88 90 92 93
(9) (12) (15) (17) (19) (21) (23) (24) (26) (27) (29) (30) (31) (32) (33) (34)
100 (38) 52 58 63 68 71 75 78 81 84 86 88 91 93 95 97 98
(11) (14) (17) (20) (22) (24) (26) (27) (29) (30) (31) (33) (34) (35) (36) (37)
To use Table 4, look down the Air Temp column and locate an air temperature in Fahrenheit or Celsius (°C values are shown
in parentheses) that corresponds to the air temperature in the area where your laser is operating. Follow this row across until
you reach a column matching the relative humidity in your location. The value at the intersection of the Air Temp and Rela-
tive Humidity columns is the Dew Point Temperature in °F (or °C). The chiller’s temperature setpoint must be set above the
dew point temperature. For example, if the air temperature is 85 °F (29 °C) and the relative humidity is 60%, then the dew
point temperature is 70 °F (21 °C). Adjust the chiller’s temperature setpoint to 72 °F (22 °C) to prevent condensation from
forming inside the laser.
Caution
possible
equipment
damage
Operating the laser at coolant temperatures above 22 °C (72 °F) may result in
decreased performance and/or premature failure of electronic components.
