Fig.3Controlpanel
PositionDescriptionExplanation
1Display
Showssymbols,menusandsettings
2
SELECTIONknob
Movethroughthemenulistsorchangesettingsand
valuesbyturningtheknobleftorright
3ENTERbuttonENTERmenuchoicesorsettingsbypressingthebutton
4RETURNbutton
StepRETURNinthemenulevelsandtoabortaninitiated
parameterchangeandrestoretheoriginalvalueby
pressingthebutton
7.1.1Displaysymbols
Symbol
DescriptionExplanation
Temp
Illustratesthecurrentset-pointforsupplyairtemperature
(fromcompletelyemptytolledsymbol).
TurntheSELECTIONknobtochoosetemperature.
PressENTERtosavethesetting.
AirowIllustratesthecurrentairow.Theairowcanbeset
manuallyin5steps:Off,Low,Nom,HighandAuto.
TurntheSELECTIONknobtochooseairow.
PressENTERtosavethesetting.
A.Ventilationoff.
1
B.Lowventilation:Canbeusedwhenleavingthe
buildingforalongerperiod
C.Nominalventilation:Willgiverequiredairchange
undernormalconditions.
D.Maximumventilation:Toincreasetheairowif
necessary.
E.Autoventilation:Willregulateafterthepre-settingfor
thedemandcontrolsettings.
SAVEVTR200/BInstallationandService
208061
8
SystemairSverigeAB
