Connecttheunittotheductsystem.Makesurethatallnecessaryaccessoriesareusedtocreatea
functionalventilationsolution.
Warning
Theinstallationoftheunitandcompleteventilationsystemmustbeperformedbyanauthorized
installerandinaccordancewithlocalrulesandregulations.
5
Connecttheunitelectricallytothemainswiththeenclosedplugandcheckthatitstartsupcorrectly.
6.4Condensationdrainage
Ingeneralnocondensationdrainageisneededforrotationalheatexchangersatdryconditions.However,
ifalotofhumidairispresentintheresidence,acondensationdrainagemightbeneeded.Drainage
connectionisavailableasanaccessoryandcanbeorderedseparate.
Note:
Thedrainageconnectionispluggedinthebottomoftheunitatdelivery.T ousethedrainage:remove
therubbersealandconnectthewaterhose.Connectthewaterhosetothesewer.Thewatercannot
beledstraighttothesewerwithoutawatertrap.
6.5Openthefronthatch
Thefronthatchismountedwithhinges.HingestotherightonanLmodelandtotheleftonanRmodel.
Openthehatchwiththetwolatchesandswingthehatchopen.
7Commissioning
Connecttheunitelectricallytothemainswiththeenclosedplug.
7.1Controlpanel
Connecttheunitelectricallytothemainswiththeenclosedplugandcheckthatitstartsupcorrectly.
Thecontrolpanelisusedtomakethenecessaryadjustments.
Anexternalcontrolpanelcanbeconnectedonthetopoftheunit.
Theillustrationbelowshowsthecontrolpanelwithashortdescription.
SAVEVTR200/BInstallationandService
208061
7
SystemairSverigeAB
