6Installation
Thissectiondescribeshowtoinstalltheunitcorrectly.Toensureaproperandfail-freeoperation,itis
importantthattheunitisinstalledaccordingtotheseinstructions.
6.1Unpacking
Verifythatallorderedequipmentaredeliveredbeforestartingtheinstallation.Anydiscrepanciesfromthe
orderedequipmentmustbereportedtothesupplierofSystemairproducts.
6.2Where/howtoinstall
TheSAVEVTR200/Bcanbeinstalledinanyroominthehousehold.
6.3Installationprocedure
1
Preparethesurfacewheretheunitistobemounted.Makesurethatthesurfaceisat,verticalandthat
itsupportstheweightoftheunit.Performtheinstallationinaccordancewithlocalrulesandregulations.
2
Fitthemountingbracket(pos.1)withthe
anti-vibrationpad(pos.2)tothewallwithenclosed
screws.Useappropriateholestoscrewthe
bracketrmlytothewall.Bottomsideofbracket
shouldbe40mm(H)belowtopofunitposition.
Note:
Makesurethatthemountingbracketiscompletely
horizontaloncemountedonthewall.Checkwitha
spiritlevel.
3
Lifttheunitinplace
Warning
Bewareofsharpedgesduringmountingand
maintenance.Useprotectivegloves.
Considertheunitweightwhenmounting!
Note:
Makesurethattheunitiscompletelyverticaland
horizontaloncemountedonthewall.Checkwitha
spiritlevel.
SAVEVTR200/BInstallationandService
