5.3.2ConnectionsLeftandRightmodels
Fig.2LeftandRightmodels
PositionDescription
R
Righthandmodel(Supplyairconnectionissituatedontherighthandsideof
theunitviewedfromthefront)
L
Lefthandmodel(Supplyairconnectionpanelissituatedonthelefthandsideof
theunitviewedfromthefront)
Symbol
Description
Symbol
Description
Symbol
Description
SupplyairOutdoorairCookerhoodair
ExhaustairExtractair
5.3.3Powerconsumptionandfusesize
SAVEVTR200/Bcomewith500Wor1000Winstalledre-heaterbattery.
Table1:Electricaldata
Re-heater(W)
500W1000W
Fans(W)
172W
Totalpowerconsumption(W)
672W1172W
Fuse(A)
10A
SAVEVTR200/BInstallationandService
208061
5
SystemairSverigeAB
