3.GotoFunctionsandselectFactoryReset
Functions
Factoryreset
4.TurntheSELECTIONknobsoYESisshown
andpressENTER.
Factoryreset
Reallyreset?YES/NO
5.ACCEPTEDisshowninthedisplaywindow
ACCEPTED
6.TheStartupWizardstartsafterapproximately
10seconds
7.3Systemcurves
Asystemrequiresdifferentpressuresatdifferentairows,whichcanberepresentedbyasystemcurve.
Theintersectionbetweenthesystemlineandthefancurve,istheunit'sworkingpoint.Itisshowingthe
airowthesystemisgoingtohave.Everychangeinthepressureoftheventilationsystem,willgive
risetoanewsystemcurve.
Ifyouchoosetodothecommissioningwithl/sorm
3
/h,youneedtoknowthesystem’spressureinorderto
chooseasuitablesystemcurve.
7.3.1Flowsettingssupplyair,F7typelter
Fig.4Supplyairowsettings,F7typelter
SAVEVTR200/BInstallationandService
208061
11
SystemairSverigeAB
