DescriptionExplanation
Service
PressENTERtoaccesstheservicemenu.
AlarmPressENTERtoaccessthealarmlist.
1.ThefancanbesettoOFFbyactivatingmanualfanstop.Seeservicemenudescriptionunderfunctions.
Important
Itisnotrecommendedtoactivatemanualfanstop(setfantoOFF)instandardhouseholds.Ifmanualfan
stopisactivated,theunitshouldbeprovidedwithdampersinexhaustandfreshairductstoavoidcold
draughtandriskofcondensationwhentheunithasbeenstopped.
7.2Startupwizard
TheStartupWizardisastep-by-stepcongurationtoolthatstartsautomaticallywhentheSAVEVTR
200/Bisstartedforthersttimeorwhen:
•afactoryresetisperformed
•anewprintcardisinstalled(sparepart)
Inthiscasetheunittypemustbeentered(SAVEVTR200/B)
TheairowintheStartupwizardcanbesetbyeitherl/s,m
3
/horapercentagewiththeFancontrol.
•IfAirflowSystemcurveischosen,thesettingswillbeinl/s,m
3
/handsystemcurvesareselected.
•IfAirflow%ischosen,thesettingswillbeinpercentage.Systemcurvesarenotselectable.
7.2.1Procedure
1.TurntheSELECTIONknobtochooselanguageandpressENTER
Languages
LanguageENGLISH
2.Chooseunittype,thischoiceisonlypresentifanewprintcardis
installed(sparepart)orwhenafactoryresetisperformed.
Type
SAVEVTR200/B
3.Setdateandtime
Time/DateYY/MM/DD
Date:12/09/12
Time:10:00
Weekday:Sat
4.Selectheater:None/Electrical/Water/Other
Note:
Thischoiceisavailableonlyafterafactoryreset,seechapter7.2.2,or
whenanewprintcardisinstalled.
Pre-heaterisonlyavailableforVTC200.
Heater
Pre-heater:YES/NO
Reheater:None/Electri-
cal/Water/Other
SAVEVTR200/BInstallationandService
208061
9
SystemairSverigeAB
