2.Openthefronthatch.
3.Removethebrokendrivebelt.
4.Usetapetoattachthedrivebelttotherotatingheatexchanger,androtatetheexchangerbyhand
togetholdofthedrivebelt.
5.Removethetapeandputthe”empty”endontothenipple.
6.Pressthedrive-beltendsrmlytowardseachothertosecurethenipple.
7.Pullthedrivebeltontothebeltpulleyandrotatetheexchangerbyhand.Checkthatthebeltpulley
rotates.
Note:
Ifthedrivebeltslips,thedrivebeltmaybetoolongandneedstobeshortened.Cutthedrivebelt5
mmandgotostep6.
8.Closeandlockthefronthatchandconnecttheunittomains.
9.CheckthatthealarmhasceasedontheControlDisplay.
Note:
Ifthealarmremains,checktherotorsensor.
10.6.2Heatexchangerremoved
1.Stoptheunitbydisconnectingthemains.
2.Openthefronthatch.
3.Disconnecttheheatexchangerpowersupplyandtherotorsensor.Thecablesarefoundbesidethe
heatexchangerattheback.
4.Pullouttheheatexchangertowardsyou.Someforcemaybeneeded.
5.Removethebrokendrivebelt.
6.Applythenewdrivebeltaroundtheheatexchanger.
7.Pressthedrive-beltendsrmlytowardseachothertosecurethenipple.
8.Pullthedrivebeltontothebeltpulleyandrotatetheexchangerbyhand.Checkthatthebeltpulley
rotates.
Note:
Ifthedrivebeltslips,thedrivebeltmaybetoolongandneedstobeshortened.Cutthedrivebelt5
mmandgotostep7.
9.Mounttheheatexchanger.Don’tforgettoreconnecttherotorpowerandsensorcables.
10.Closethefronthatchandconnecttheunittomains.
11.CheckthatthealarmhasceasedontheControlDisplay.
Note:
Ifthealarmremains,checktherotorsensor.
SAVEVTR200/BInstallationandService
208061
41
SystemairSverigeAB
