IP Ethernet Mode
MENU: Ethernet Mode
Auto
Auto
10Base-T Half Duplex
10Base-T Full Duplex
100Base-TX Half Duplex
100Base-TX Full Duplex
This menu is used to force the IP module to a
specific IP configuration. This is useful when
interfaceing to Fibre modems that do not support HP
MDIX.
IP Packet Size
MENU: Packet Size
Defualt
Defualt
1-19 mS
This is used to define how many Ms of audio is
captured in each transmitted packet. If left on default
then the codec will choose the standard packet size
for that audio mode. However, if required you can
adjust the packet size to lower the delay on your
AoIP link.
The receive side of the AoIP link will always adapt to
the size of the packets being received.
SIP Remote Port
MENU: SIP Remote Port
5060
The remote port for the SIP algorithum can be
changed here.
SIP Local Port
MENU: SIP Local Port
5060
The local port for the SIP algorithum can be
changed here.
SIP Audio Port
MENU: SIP Audio Port
5050
The audio port for steaming can be changed here.
SIP Public IP
MENU: SIP Public IP
29.10.0.2
If the codec is sitting behond a NAT router it can be
usfull to configure this entry with the public Ip
address that would be seen by the outside world
when trying to make a connection.
X21 Audio
MENU: X21 Audio
APTX: 15K2 Stereo 256Kbps
The and buttons can be used to select the
required X21 Audio format:
APTX: 22K5 Stereo 384Kbps
APTX: 15K2 Stereo 256Kbps
APTX: 22K5 Mono 192Kbps
APTX: 12K2 Stereo 192Kbps
APTX: 15K2 Mono 128Kbps
APTX: 7K5 Stereo 128Kbps
APTX: 7K5 Mono 64Kbps
APTX: 3K7 Stereo 64Kbps
NOTE: When operating in Mono, only the Left Input and Left
Output audio channels will be active if the Audio Mixing
option has been switched OFF.
Backup Options
The user can modify the configurations associated
with the automatic ISDN Backup and Restore
operation.
Backup Monitor
INFO: Backup Monitor
0% X21 Sync Errors
This menu displays the percentage of Sync Loss
Errors in the last 10 seconds.
Page 11
