numerical keypad. The button backspaces to edit
a number once it has been confirmed. On
completion press the YES button to save the
changes, and the NO button to abort the changes.
If a Mutlicast address is specified and AutoCon
initiated, then the codec will automatically initiate
IGMP2 to join the multicast group as either a sender
or receiver (as specified in the mode menu).
IP Link 1 Algorithm
MENU: IP Link 1 Algorithm
APTX
The and buttons can be used to select the
required IP Audio Algorithm :-
APTX
PCM
G722
Note: All transmit audio modes are required to be
the same format. If the user attempts to connect in a
format that does not match the current operational
mode then the codec will automatically override the
user setting.
IP Link 1 Format
MENU: IP LINK 1 FORMAT
Stereo
The Audio Format of the audio can be selected.
Mono
Stereo
IP Link 1 Sample Rate
MENU:IP LINK 1 SAMPLERATE
48KHz
The Sample Rate of the IP Audio can be selected.
48K
32K
16K
8K
IP Link 1 Mode
MENU: IP LINK 1 MODE
Duplex
The IP Audio Mode can be selected.
Duplex
Transmit
Receive
No Audio
Note: If Multicast is selected then only Transmit or
Receive options are valid.
IP Link 1 FEC
MENU: IP LINK 1 FEC
OFF
The Forward Error Control FEC mode can be
selected as follows :-
OFF - No FEC used.
4 - Ratio of lost packets which can be 100%
recovered is 1 in 4.
8 - Ratio of lost packets which can be 100%
recovered is 1 in 8.
IP Link 1 AutoCon
MENU: IP LINK 1 AUTOCON
ON
The C500ip can be configured to Auto-Connect if
the IP connection is disrupted for any reason
including power reset.
IP Local Options
MENU: IP LOCAL OPTIONS
The next level of the menu system allows the user
to modify the Local IP parameters.
IP Local Name
MENU: IP LOCAL NAME
LONDON CODEC 2 / 0109-006
An IP Local Name can be changed by the user and
is used to identify a specific C500ip Codec. The
factory default name is the serial number of the unit.
Page 9
