MENU SYSTEM
The menu system on the C530ip Audio Codec has
been designed to allow the user to configure the unit
with ease. Six keys are used to drive the menu
system :-
UP
DOWN
RIGHT / EDIT
BACKSPACE
YES CONFIRM EDIT
NO CANCEL EDIT / LEFT
Unit Description / Title
The software release and serial number of the unit
are displayed on the Title screen.
SYSTEMBASE C530ip
REL 001 S/N 0108-001
IP Link Status
MENU: IP Link Status >
IP1: Stream IP2: Idle
The button is used to display the status
information of the IP Links :-
INFO:IP I STREAM>DUPLEX
NAME:0109-007
The or down buttons may be used to cycle
through the available IP links.
Audio Status
The status of the received audio, the audio format
and the data rate of the codec.
INFO: Audio Status SYNC>
APTX:7K5 Mono 64Kbps
The codec has been designed to Mute the audio
signal if end-to-end synchronisation is not achieved.
The data rate displayed is the actual data rate which
the codec has achieved end-to-end synchronisation
and not necessarily the configured mode.
The button may be used to display information
about the AES input data stream.
INFO: Aes Status
RX=Con FMT=Pro VLD=PCM
RX is the status of the AES audio receive signal.
Con = Connected, Dis = Disconnected
FMT is the AES format.
Pro = Professional, Con = Consumer
VLD is the AES Valid Bit
PCM = PCM, Dat = Data
IP Options
MENU: IP Options
The next level of the menu system allows the user
to modify the parameters associated with IP
operation of the unit by pressing the button.
IP Remote Options
MENU: IP Remote Options
The next level of the menu system allows the user
to modify the parameters associated with IP Remote
Links.
IP Link 1..6 Options
MENU: IP LINK 1 OPTIONS
The IP parameters associated with each IP Link can
be changed.
The following 7 option menus are repeated for all IP
Links.
IP Link 1 Address
MENU: IP Link 1 Address
198.0.0.8
The IP Remote Address can be entered using the
Page 8
