The Alarm output can be configured to the following
options:
Off
Sync Loss
Backup
Headroom
MENU: Headroom
+12dBu
Headroom can be configured to either level.
System Options
The user can modify the global System
configurations of the Codec.
Password
MENU: Password
Not Set
The C530ip has two levels of password protection to
avoid accidental re-configuration; Edit Lock and Full
Lock.
Loopback
MENU: Loopback
Off
The C530ip can be configured to provide an internal
digital loopback of the compressed audio signal
prior to the X.21 / ISDN interface. The loopback
function will automatically use the highest data rate
available.
NOTE : The loopback function is not available when
operating in Backup Master or Backup Slave modes.
SNMP
MENU: SNMP
Off
The C530ip can be configured to support SNMP
Management. Please contact Systembase Limited
to request the MIB file.
Ethernet Options
MENU: Ethernet Options
100BASE-TX full-duplex
The C530ip can be remotely managed via the
Ethernet Port. The display will show:-
Inactive,
Negotiation,
100BASE-TX full-duplex,
100BASE-TX half-duplex
10BASE-TX full-duplex
10BASE-TX half-duplex
Ethernet DHCP
MENU: Ethernet DHCP
ON / OFF
When Dynamic Host Configuration Protocol (DHCP)
is selected to ON the C530ip will request a
temporary IP Address from the IP Server and
thereby simplifying the setup process.
IP Address
MENU: Ethernet IP
192.168.001.002
The current Ethernet IP Address of the codec can
be configured.
Ethernet Mask
MENU: Ethernet MASK
255.255.255.000
The Subnet Mask associated with the Ethernet IP
address of the codec can be configured.
Ethernet Gateway
MENU: Ethernet GATEWAY
192.168.001.001
The Gateway associated with the Ethernet IP
address of the codec can be configured.
Set Defaults
MENU: Set Defaults
The codec can be re-configured back to the Factory
Page 13
