M503 Series chair Scales Service Manual (3.09)
- 14 -
F3 prt
P cont
Cont 1
Send data continuous, use protocol of
Tscale
Cont 2
Send data continuous, use protocol of
Toledo
Cont 3
Send data continuous, use special
protocol
P auto
Automatic accumulation.
Individual weighing values are automatically added
Ask
ASK mode
Command W: read the data at the moment
Command S: read the data when stable
Command T: Tare
Command Z: Zero
P stab
Send data when the weighing values is stable
P cnt2
another continuous mode.
Set BAUD rate
After setting the RS 232 mode, display will be shown current baud
rate b XXX.
Baud rate Options: b600, b1200, b2400, b4800 and b9600
Set print out format
If enter settings p prt, p auto and connected with optional printer
Prt 0-3
M+ format- Date/Time
Lp-50 /
tpup
Printer LP-50 or Tp-up
F4 bk
Bl on
Set the backlight always on.
Bl off
Set the backlight always off.
Bl au
Set the backlight automatic on.
Tch
pin
Enter the password
P 1 spd
Set A/D convert speed(7.5/15/30/60)
P 2 Cal
SNG RA
desc
Set decimal point
Inc
Set increment
cap
Set capacity
cal
Enter calibration
Dual int
desc
Set decimal point
Inc
Set increment of dual range
Sdiv 1：increment of first range
Sdiv 2
：
increment of second range
cap
Set capacity of dual range
Cap1
: capacity of first range
