M503 Series chair Scales Service Manual (3.09)
- 5 -
 Strong magnetic fields should be avoided when using. It will influence the
weighing of the scale.
3. SPECIFICATION
3.1 Specifications
Model
M501-250k
Maximum Capacity
300kg
Readability
100g
Resolution
1/2,500
Tare range
-299.9kg
Minimum Capacity
2000g
Linearity ±
200g
Common Specifications
Interface
RS-232 Output Optional
Stabilisation Time
2 Seconds typical
Operating Temperature
-10℃-40℃
Power supply (external)
12V/500mA AC power adapter or 2000mAh Ni-MH
batteries (optional, size AA)
Calibration
Automatic External
Calibration as per Directive
90/384/EEC
Class III medical approval
Medical product as per
Directive 93/42/EEC
Class I
ADC
Σ-Δ
Display
25 mm high 6 digits LCD with auto backlight and
loading bar graph
Housing
Aluminium platform, ABS plastic indicator
Gross weight
75kg
