Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 16
Actual status of control word 2.
Control word 2 can be controlled by two different sources (field bus, digital inputs, PG4000 or U-drive
Manager)!
The bits for both control words (Par.556 to 557) are incorporated in control word 2 or linked
(1=dominant).
At stop, the drive delays with the active ramp
After a controlled run down (the fall time will be bridged by the holding
brake)
CurLimitAfterOverloadTimeMotCur
Only allowed for the amount of time set in Par.109.
CurLimitAfterOverloadTimeDrvCur
Only allowed for the amount of time set in Par.109.
Suppress error message rotor position sensor for fault diagnosis.
Suppress error message rotation sensor for fault diagnosis
DisDrvByRefAndActSpEquZero
Controller interlock occurs when setpoint and actual values = 0
Controller cannot be started when rotation speed setpoint > 0
Torque setpoint can be specified via Par.103
controller portion takes place when this bit is set
After switching the drive off and back on again, drive will not be
intercepted at current rotational speed. The drive will coast to a stop and
then starts again.
Enables the phase correction (Par.38) of the electronic commutation.
Should only be adjusted if controller is interlocked, otherwise current
overloads may occur.
