tae TA-U110 User Manual

Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 17
13: Command/Status Words
ID
Name
Value-Range
Default-Value
Unit
Access
560
General Stat
0000h ... FFFFh
---
[bits]
R
Displays the most important operation conditions for the drive.
Bit
Name
Notes
0
Ready
1
Running
2
Speed > 0
3
Speed > X
Also see Par.510
4
Powerstage active
5
I-Limit reached
Also see Par.512
6
I > X
Also see Par.511
7
Generator Mode
8
Collective Error
9
Value out of range
10
Set-Value reached
11
n-set/n-act in tolerance range
Tolerance = 1% of the max. rotational speed (Par.101)
12
Fieldbus controlling
13
Current > Motor Rated Current
14
Field Weakening active
15
Asynch Control active
Asynchronous motor active
13: Command/Status Words
ID
Name
Value-Range
Default-Value
Unit
Access
561
Motor Stat
0000h ... 000Fh
---
[bits]
R
Display of auto-tuning status (ASM)
Bit
Name
Notes
0
Auto tuning started
1
Auto tuning and run
2
Auto tuning finshed
13: Command/Status Words
ID
Name
Value-Range
Default-Value
Unit
Access
562
Drive Stat
0000h ... FFFEh
---
[bits]
R
565
Spd Prst Sel
[00] --- ... [07] Spd Preset 7
[00] ---
[bits]
RW
566
Ramp Sel
[00] Ramp 0 ... [07] Ramp 7
[00] Rampe 0
[bits]
RW
13: Command/Status Words
ID
Name
Value-Range
Default-Value
Unit
Access
567
Selected Reference Speed Source
[00] Preset Speed ...[08] Positioning
---
---
R
Display of active setpoint reference sources
Nr.
Name
Notes
0
Preset Speed
1
2
3
Analog input Terminal 8
4
Master/Slave
Incremental
5
Motorpoti
6
Fieldbus
7
8
Positioning
