tae TA-U110 User Manual

Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 18
14: Error-Status
ID
Name
Value-Range
Default-Value
Unit
Access
570
Control Messages
0000h ... 00DAh
---
[bits]
R
Display of prewarning and conditions which cause the drive to malfunction.
Bit
Name
Notes
0
Drive Temp Prew C1
Controller temperature is close to shut-off! (See Par.513)
1
Motor Temp Prew C2
Motor temperature is close to shut-off! (See Par.509)
2
Value Out Of Range C3
Value outside the permissible value range
3
Emergency Stop C4
No voltage at terminals L+/L- (24VDC)
4
Enable Drive by Ref. Speed Equal Zero C5
Drive can only start when the setpoint = 0! (See Par.555 Bit 9)
5
Drive disabled C6
e.g.: repair switch is open
6
Actual Speed GT Speed Calibration C7
e.g.: motor is overshooting
7
Parametring error C8
Physical motor parameters for this type of controller are outside of
possible range!
8
Direction inhibited C9
Selected direction of rotation is blocked. (See Par.555 Bit 6 or 7)
14: Error-Status
ID
Name
Value-Range
Default-Value
Unit
Access
571
Failures
0000h ... FFFFh
---
[bits]
R
Error messages which cause the drive to malfunction.
Bit
Name
Notes
0
Overcurrent F1
Short circuit – Incorrect end stage, motor or motor cable or physical data of
the motor! (See Par.74)
1
IGBT F9
Defective end stage or short circuit or earth fault at motor connection!
2
Ripple Current F5
Defective intermediate circuit electrolytic capacitor, missing network phase
oder brief mains voltage failure!
3
Overvoltage F4
Intermediate circuit voltage too high: brake resistance highly resistive or
generating operation without braking unit! (See Par.501)
4
Undervoltage F3
Intermediate circuit voltage too low, failure in mains voltage, missing
network phase or defective or non-functioning internal charging relay! (See
Par.502)
5
Drive Over Temperature F2
Controller permanently overloaded: ambient temperature too high, non-
functioning switching cabinet or equipment ventilation or equipment
improperly installed in switching cabinet (heat accumulation). (See Par.500)
6
Drive Temperature Pre-Warning C1
Controller temperature is close to shut-off! (See Par.513)
7
Position Sensor F6
Defective rotor position sensor in motor or defective sensor cable, incorrect
connection, or motor or sensor cable incorrectly shielded!
8
Speed Sensor F7
Defective rotation speed sensor in motor or defective sensor cable, incorrect
connection, or motor or sensor cable incorrectly shielded or mix-up in Tracks
A and B!
9
Electronic Failure F8
Internal processor is not working!
10
Drive disabled C6
e.g.: repair switch is open
11
Emergency Stop C4
No voltage at terminals L+/L- (24VDC)
12
Motor Over Temperature F0
Motor permanently overloaded, defective temperature probe or probe wire!
13
Motor Temperature Pre-Warning C2
Motor temperature is close to shut-off! (See Par.509)
14
Brake FeedBack Signal Error E3
Feedback: Incorrect electromechanical brake! (See parameter group 20)
15
External Error E1
Error caused externally! (e.g.: overload relay from external motor fan)
14: Error-Status
ID
Name
Value-Range
Default-Value
Unit
Access
572
DSP_Errors
0000h ... FFFFh
0000h
R
573
StatusParaError
0000h ... FFFFh
0000h
[bits]
R
574
StatusParaError2
0000h ... FFFFh
0000h
[bits]
R
575
StatusParaError3
0000h ... 1FFFh
0000h
[bits]
R
576
StatusParaError4
0000h ... 001Fh
0000h
[bits]
R
