3.4 Principle Diagrams
3.4.1 TA-U1..U6
External
brake resistor
R
L2 L3 L1
-24V
DC
DC
Chopper
+24V
W
L-
L+
V
U
R1
-
R2
+
GL1
IGBT-Control
EMC-Filter
L1
E1
Charge resistor
LP4
LP8
LP9
LP6
LP2
Thermal switch
Brake resistor
Positive
Negative
43
L1
12
PT100
LP7
X14
41
-24V
X6
123
X7 X12 X13
1121223
X1
X4
X1
PowerStage
CPU - Controlboard
Digital - Analog
boards
& Bus systems
Encoder-Systems
Displayboard
24V DC
Safe Stop
1-
1+
External
Elektronic supply
max 710V DC
Option
