tae TA-U55 User Manual

Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 10
09: Analog I/O
ID
Name
Value-Range
Default-Value
Unit
Access
230
A-IN 68 Mode
[00] 0~10V ... [05] 0~-10V
[00] 0~10V
RW
231
A-IN 68 Offset
0 ... 32767
---
RW
232
A-IN 68 Gain
0,00 ... 105,00
100,00
RW
233
A-IN 68 Dest-Parameter
0 ... 65535
---
RW
234
A-IN 68 Act Value
-32767 ... 32767
---
R
Analog input terminal 68-72: (Bipolar)
Same as Par.220-224 except that negative values are possible.
Nr.
Name
Notes
0
0-10V
1
0-20mA
2
4-20mA
3
+10-(-10V)
4
-10-(+10V)
5
0-(-10V)
09: Analog I/O
ID
Name
Value-Range
Default-Value
Unit
Access
240
A-IN 70 Mode
[00] 0~10V ... [05] 0~-10V
[00] 0~10V
RW
241
A-IN 70 Offset
0 ... 32767
---
RW
242
A-IN 70 Gain
0,00 ... 105,00
100,00
RW
243
A-IN 70 Dest-Parameter
0 ... 65535
---
RW
244
A-IN 70 Act Value
-32767 ... 32767
---
R
250
A-IN 72 Mode
[00] 0~10V ... [05] 0~-10V
[00] 0~10V
RW
251
A-IN 72 Offset
0 ... 32767
---
RW
252
A-IN 72 Gain
0,00 ... 105,00
100,00
RW
253
A-IN 72 Dest-Parameter
0 ... 65535
---
RW
254
A-IN 72 Act Value
-32767 ... 32767
---
R
09: Analog I/O
ID
Name
Value-Range
Default-Value
Unit
Access
260
A-OUT 74 Mode
[00] 0~10V ... [05] 0~-10V
[00] 0~10V
RW
Analog output terminal 74:
Selecting the physical output variable. (Bipolar)
Analog outputs are configured to a voltage in the factory; when used as a current outputput (e.g. 4-20mA),
the dip switch position of the output has to be altered! (See wiring diagram)
Nr.
Name
Notes
0
0-10V
1
0-20mA
2
4-20mA
3
+10-(-10V)
4
-10-(+10V)
5
0-(-10V)
09: Analog I/O
ID
Name
Value-Range
Default-Value
Unit
Access
261
A-OUT 74 Offset
-32767 ... 32767
---
RW
262
A-OUT 74 Gain
0,00 ... 105,00
100,00
RW
263
A-OUT 74 Src-Parameter
0 ... 1200
520
RW
264
A-OUT 74 Norm Value
0 ... 32767
---
RW
265
A-OUT 74 Act Value
-32767 ... 32767
---
R
