tae TA-U55 User Manual

Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 14
10: PLC I/O
ID
Name
Value-Range
Default-Value
Unit
Access
403
OUT Polarity
00000000h ... FFFFFFFFh
FFFFFFFFh
RW
410
IO N_Inputs
0 ... 32
---
R
411
IO N_Outputs
0 ... 32
---
R
412
Valid Input
00000000h ... FFFFFFFFh
---
R
413
Valid Output
00000000h ... FFFFFFFFh
---
R
414
IO_ActIN
00000000h ... FFFFFFFFh
---
R
415
IO_ActOUT
00000000h ... FFFFFFFFh
---
R
11: Monitoring-Limits
ID
Name
Value-Range
Default-Value
Unit
Access
500
Drive Over-Temp Limit
0,0 ... 85,0
80,0
°Cel
RW
501
Drive Over-Voltage Limit
0 ... 800
780/390
V
R
502
Drive Under-Voltage Limit
0 ... 800
360/205
V
R
503
Drive Over-Current Limit
0,000 ... Par.74
---
A
R
504
Drive Brake-Chopper Off Voltage
1 ... 800
740/365
V
R
505
Drive Brake-Chopper On Voltage
1 ... 800
750/375
V
R
506
Motor Max Speed electr.
0,0 ... Par.75
---
rpm
R
507
Motor Max Speed mech.
0,0 ... Par.75
---
rpm
R
508
Motor Over-Temp Limit
0,0 ... 250,0
---
°Cel
RW
509
Motor Warn Temp Limit
0,0 ... 250,0
---
°Cel
RW
510
Speed detect Limit
0,0 ... Par.75
300,0
rpm
RW
511
Current detect Limit
0,00 ... Par.104
Par.28
A
RW
512
Delayed Message Current limit reached
0,0 ... 1000,0
5,0
s
RW
513
Drive Warn Temp Limit
0,0 ... 80,0
75,0
°Cel
RW
514
Under-Voltage delay time
0 ... 60000
---
ms
RW
12: Actual Values
ID
Name
Value-Range
Default-Value
Unit
Access
520
Act Speed
-1000,0 ... 1000,0
---
rpm
R
521
Ref Speed
-1000,0 ... 1000,0
---
rpm
R
522
Actual Current
0,00 ... 0,00
---
A
R
523
Motor Torque
0,00 ... 2147483647,00
---
Nm
R
524
Buss Voltage
0 ... 800
---
V
R
525
Motor Temp. Terminal 22
-320,0 ... 320,0
---
°Cel
R
526
Motor Pre.-Temp. Terminal 21
-320,0 ... 320,0
---
°Cel
R
527
Drive Temp.
-267,0 ... 267,0
---
°Cel
R
528
Actual Lead Speed
-1000,0 ... 1000,0
---
rpm
R
529
Machine Speed
0,000 ... 2147483647,000
---
--
R
530
Act Pulse Frequency
1,00 ... 20,00
---
kHz
R
531
Motor Current U
-100,00 ... 100,00
---
A
R
532
Motor Current V
-100,00 ... 100,00
---
A
R
533
Motor Current W
-100,00 ... 100,00
---
A
R
534
Brake Chopper Volt
0,0 ... 800,0
---
V
R
535
n-Controller Ref Speed
-1000,0 ... 1000,0
---
rpm
R
536
n-Controller Act Speed
-1000,0 ... 1000,0
---
rpm
R
537
n-Controller Deviation
-1000,0 ... 1000,0
---
rpm
R
538
n-Controller Output
-100,00 ... 100,00
---
A
R
539
Actual Current unfiltered
0,00 ... 0,00
---
A
R
540
ASM minimum flux
-32767 ... 32767
---
R
541
ASM rated flux
-32767 ... 32767
---
R
542
Flux Weakening
0,00 ... 0,00
---
A
R
546
Drive Working minutes
0 ... 59
---
min
R
547
Drive Working hours
0 ... 2147483647
---
h
R
548
Drive Operating minutes
0 ... 59
---
min
R
549
Drive Operating hours
0 ... 2147483647
---
h
R
