Taie FA Series User Manual

9
z Optional Spec.
Model FY400 /
FU48
FY600 FY700 /
FU72
FY800 /
FU86
FY900 /
FU96
FY100 FY101
Output 2
For heating and cooling control use.
Relay , SSR , 4~20mA , 0~20mA , 0~5V , 0~10V , 1~5V , 2~10V
Available Available Available Available Available Available
SPST type SPDT type SPST type SPDT type SPDT type SPDT type
Not
available
Alarm 2
3A , 220V , electrical life:100,000 times or more (under rated load)
Available Available Available Available Available Not
available
SPST type SPST type SPST type SPST type SPST type
Not
available
Alarm 3
3A , 220V , electrical life:100,000 times or more (under rated load)
Display range of heater current : 0.0~99.9A , Accuracy : 1%FS
Included CT : SC-80-T (5.8mm dia , 0.0~80.0A)
or SC-100-T (12mm dia , 0.0~99.9A)
Heater Break Alarm
(HBA)
Alarm relay : AL1
Available for PV or SV transmission
Transmission
4~20mA , 0~20mA , 0~1V , 0~5V , 0~10V , 1~5V , 2~10V
Remote SV
4~20mA , 0~20mA , 0~1V , 0~5V , 0~10V , 1~5V , 2~10V
Protocol : MODBUS RTU , MODBUS ASCII , TAIE
RS232 , RS485 , TTL
Baud rate: 2400 , 4800 , 9600 , 19200 , 38400 bps.
Communication
Data bits : 8 , Stop bit : 1 or 2bit , Odd or Even parity.
Water/Dust proof
IP65
z
Special control output (OUT1)
Model FY400 /
FU48
FY600 FY700 /
FU72
FY800 /
FU86
FY900 /
FU96
FY100 FY101
1φ zero crossing
control(1φSSR)
Available Not
available
Available Not
available
Available Not
available
Not
available
3φ zero crossing
control(3φSSR)
Not
available
Available Not
available
Not
available
Motor valve control
Available
1φ phase angle
control(1φSCR)
Not
available
Available Available Not
available
3φ phase angle
control(3φSCR)
Not available Available Not
available
Not
available
