Taie FA Series User Manual

8
3 FY / FU Series
z Standard spec.
Model FY400 /
FU48
FY600 FY700 /
FU72
FY800 /
FU86
FY900 /
FU96
FY100 FY101
Dimension
48X48mm 96X48mm 72X72mm 48X96mm 96X96mm 175X110mm 90X90mm
Supply voltage
AC 85~265V，DC 15~50V (Option)
AC 85~265V
Frequency
50 / 60 HZ
Power
consumption
approx
3VA
approx
4VA
approx
3VA
approx
4VA
approx
4VA
approx
4VA
approx
3VA
Accuracy
0.2 % FS ± 1digit
Sample time
250ms
TC
K , J , R , S , B , E , N , T , W5Re/W26Re , PLII , U , L
RTD
PT100,JPT100,JPT50
mA dc
4~20mA ,0~20mA
mV / V dc
0~1V,0~5V,0~10V,1~5V,2~10V
-10~10mV,0~10mV,0~20mV,0~50mV,10~50mV
Input
Decimal point
position
0000 , 000.0 , 00.00 , 0.000
Available for linear input (mA / mV / V)
SPST type SPDT type SPST type SPDT type SPDT type SPDT type SPDT type
Relay
3A , 220V , electrical life:100,000 times or more (under rated load)
Voltage pulse
For SSR drive. ON : 24V , OFF : 0V , max load current : 20mA
mA dc
4~20mA, 0~20mA. Maximum load resistance:560 Ω
Output 1
Voltage dc
0~5V , 0~10V , 1~5V , 2~10V . Max load current:20mA
Alarm 1
3A , 220V , electrical life:100,000 times or more (under rated load)
Control algorithm
PID，PI，PD，P，ON / OFF(P=0)，FUZZY。
PID range
P: 0.0 ~ 200.0 %，I: 0~3600s，D: 0~900s
Isolation
Output terminals(control output , alarm , transmission) and input
terminals are isolated separately
Isolated resistance
10MΩ or more between input and case (ground) at DC 500 V
10MΩ or more between output and case (ground) at DC 500 V
Dielectric strength
1000V AC for 1 minute between input terminal and case (ground)
1500V AC for 1 minute between output terminal and case (ground)
Operating
temperature
0~50℃
Humidity range
20~90%RH
Weight
150g 225g 225g 225g 300g 130g 80g
Display Height
PV:7mm
SV:7mm
PV:7mm
SV:7mm
PV:14mm
SV:10mm
PV:7mm
SV:7mm
PV:14mm
SV:10mm
