7
2.4 Assembly & Wiring
plug-in-out terminal M2.0 using “－”screwdriver fix terminal M2.6 using “＋”screwdriver
Selecting suitable electric wire of AWG 16 ~ AWG22 Lock Screw torque: 0.3 N.m (3 kgf.cm)
