TB8100 Service Kit User’s Manual Notifying Alarms 161
3. In the Pip method box, select an option that specifies how the pip tones
are sent.
4. In the Pip interval box, specify the interval between pip tone
transmissions.
5. In the Pip level box, specify the level of the pip tones in dB. This level is
relative to the line level specified in the channel profile for the current
channel.
Option Description
Tail transmission A single pip tone is sent down the line at the end of
every transmission
Periodically with Tx A pip tone is sent down the line at the beginning of
each transmission and regularly during the
transmission at the interval specified by the Pip
interval box.
Periodically with no Tx A pip tone is sent down the line regularly when the
base station is not transmitting RF. Pip tones are
transmitted at intervals specified by the Pip interval
box.
