60 Network Circuitry TB9100 Reciter Service Manual
© Tait Electronics Limited January 2006
PB16 O/P Reciter high-
speed digital
input 0
PB17 O/P Reciter high-
speed digital
input 1
PB18 O/P Reciter high-
speed digital
input 2
PB19 O/P Reciter Tx key
PB20 O/P Antenna relay
control
“Antenna Relay Control” on page 73
PB21 O/P M-lead output “M-Lead Interface” on page 80
PB22 O/P General-purpose
digital output 6
“RSSI Output” on page 73
PB23 O/P General-purpose
digital output 7
“RSSI Output” on page 73
PC6 O/P none
PC7 O/P none
PC8 O/P none
PC9 O/P Option link
PC10 O/P none
PC11 O/P none
PC12 I/P E-lead input
PC13 I/P Exciter power
status
PC14 I/P Receiver power
status
PC15 I/P Reciter power
status
IPA0 I/P General purpose
digital input 0
“General-purpose Digital Inputs” on page 72
IPA1 I/P General purpose
digital input 1
“General-purpose Digital Inputs” on page 72
IPA2 I/P General purpose
digital input 2
“General-purpose Digital Inputs” on page 72
Table 5.9 Parallel I/O Ports (Continued)
Pin Name Direction Function Reference
