Ref. IPN Description
Ref. IPN Description
Ref. PCB Circuit Ref. PCB Circuit
Ref. PCB Circuit
104 Installing an Enhanced Remote Kit TM8100/TM8200 Accessories Manual
© Tait Electronics Limited August 2005
C1 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C2 015-07470-20 CAP Cer 1206 4u7 10% 25V X7R
C3 015-06470-01 Cap Cer 1206 470n X7r 20% 50v
C4 018-13100-00 Cap 0603 100p 50v NPO ±5%
C7 015-27100-08 Cap Cer 0805 X7R 1uF 16V 10%
C9 018-13100-00 Cap 0603 100p 50v NPO ±5%
C10 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C13 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C15 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C17 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C101 018-16100-00 Cap 0603 100n 16v x7r + - 10%
C102 015-07470-20 CAP Cer 1206 4u7 10% 25V X7R
C103 015-07470-20 CAP Cer 1206 4u7 10% 25V X7R
C203 018-13270-00 Cap 0603 270p 50v NPO±5%
C207 018-13270-00 Cap 0603 270p 50v NPO±5%
C209 018-13270-00 Cap 0603 270p 50v NPO±5%
C213 018-13270-00 Cap 0603 270p 50v NPO±5%
DS1 008-00014-73 LED Hp Grn Rang PCB Mtg
J1 240-10000-11 Conn SMD 18w Skt M/Match
J2 240-00016-00 Conn RJ45 Shld 8P8C LP RA TH
J3 240-00016-00 Conn RJ45 Shld 8P8C LP RA TH
R1 038-13120-00 RES 0603 120R 5% 1/10W
R2 038-10000-00 RES 0603 0R
R3 038-15820-10 RES 0603 82k 1% 1/10W
R4 038-15820-10 RES 0603 82k 1% 1/10W
R6 038-15220-10 RES 0603 22k 1% 1/10W
R7 038-15100-10 RES 0603 10k 1% 1/10W
R8 038-15820-10 RES 0603 82k 1% 1/10W
R9 038-13100-10 RES 0603 100R 1% 1/10W
R10 038-15100-10 RES 0603 10k 1% 1/10W
R12 038-16100-10 RES 0603 100k 1% 1/10W
R13 038-16100-10 RES 0603 100k 1% 1/10W
R14 036-13560-10 RES 0805 560R 1% 1/8W
R15 038-15820-10 RES 0603 82k 1% 1/10W
R16 038-15100-10 RES 0603 10k 1% 1/10W
R17 038-15220-10 RES 0603 22k 1% 1/10W
R18 038-13220-10 RES 0603 220R 1% 1/10W
R19 038-14120-10 RES 0603 1k2 1% 1/10W
R20 038-10000-00 RES 0603 0R
R21 038-10000-00 RES 0603 0R
R30 038-13390-10 RES 0603 390R 1% 1/10W
R31 038-13390-10 RES 0603 390R 1% 1/10W
R40 036-00000-01 RES 1206 0R 5% 0.25W
R103 038-12100-10 RES 0603 10R 1% 1/10W
R104 038-15100-10 RES 0603 10k 1% 1/10W
R203 038-13100-10 RES 0603 100R 1% 1/10W
R207 038-13100-10 RES 0603 100R 1% 1/10W
R209 038-13100-10 RES 0603 100R 1% 1/10W
R213 038-13100-10 RES 0603 100R 1% 1/10W
R911 036-00000-01 RES 1206 0R 5% 0.25W
R915 036-00000-01 RES 1206 0R 5% 0.25W
R917 038-10000-00 RES 0603 0R
U1 002-19120-00 IC TS912ID Cmos R2R Opamp
U2 002-12523-17 IC LM317l Reg T0252 0.5a
U3 002-13483-00 IC XCVR RS485 LTD SLEW RATE 3V
219-02950-00 CBL MFX Remote Kit Gnd Lead
220-01720-03 PCB MFX Radio Remote
219-02882-00 Loom Control Head TMA
302-10063-00 Brkt PCB Remote TM8200 Body
302-50002-00 Bung RJ45 MFO
316-06843-00 Pnl Frt Remote TM8200 MF0
11.4.2 TMAC34-0T Torso Interface (PCB IPN 220-01720-03)
Parts List
Grid Reference List
C1 1:J2 1F5
C2 1:K1 1F4
C3 1:D2 1F1
C4 1:J1 1F6
C7 1:J2 1E5
C9 1:K2 1E6
C10 1:N2 1E7
C13 1:N2 1E7
C15 2:L2 1F8
C17 2:L2 1F6
C101 1:J1 1F3
C102 1:D1 1F2
C103 1:E2 1B5
C203 1:J2 1B4
C207 1:H2 1B3
C209 1:H2 1B4
C213 1:H1 1B4
DS1 1:F2 1F2
J1 1:H2 1C1
J2 1:N2 1C10
J3 1:L2 1E10
MT1 1:R2 1D10
R1 2:N2 1C8
R2 2:P2 1C7
R3 1:J1 1G4
R4 1:J1 1F4
R6 1:J1 1F5
R7 1:G2 1C3
R8 1:J1 1F6
R9 2:L2 1G6
R10 1:K2 1E6
R12 1:N2 1E7
R13 1:N2 1E7
R14 1:F2 1F2
R15 2:L2 1F7
R16 1:H2 1B3
R18 1:D2 1F2
R17 2:L2 1F7
R19 1:E2 1F2
R20 2:L2 1F8
R21 1:N2 1E7
R30 1:F2 1B8
R31 1:E2 1C7
R40 2:N2 1D9
R103 1:G2 1B5
R104 1:G2 1C5
R203 1:J2 1C3
R207 1:J2 1C3
R209 1:H2 1C3
R213 1:H2 1B3
R820 2:L2 1F8
R821 1:N2 1E8
R900 1:F2 1C7
R920 1:D2 1G2
R910 2:J2 1C8
R901 1:E2 1C7
R911 2:L2 1D9
R912 1:H2 1C3
R915 2:M2 1D9
R916 1:M2 1D9
R917 1:N2 1D9
R918 2:M2 1E9
U1 1:K1 1G6
1E6
1F3
U2 1:D2 1F1
U3 1:F2 1C6
