Tait tm8200 Accessories Manual

TM8100/TM8200 Accessories Manual Installing a Remote Kit 85
© Tait Electronics Limited August 2005
Ref. PCB Circuit Ref. PCB Circuit
Ref. PCB Circuit
C101 F3 1D2
C102 F2 1D3
C103 K1 1D5
C104 F4 1E3
C105 E4 1D3
C106 G1 1C4
C107 F1 1C2
C108 G1 1C3
C109 E4 1C3
C110 F4 1B2
C111 F4 1B2
C112 M3 1E5
C113 M3 1D5
C114 M3 1E6
C115 M3 1D6
C116 M4 1D6
C117 M4 1D6
D101 J2 1C4 1C5
D102 J1 1C4
D103 G4 1E2
D104 J4 1E3
D105 F4 1D4 1D3
D106 D4 1B2
D107 M4 1D7
E101 F3 1B2
E102 F4 1B3
E103 G1 1C3
E104 G1 1C3
E105 K3 1D1
E106 D3 1D1
E107 E4 1D2
E108 E4 1C2
E109 K1 1D5
F101 F3 1D2
J100 E4 1C1
J101 L2 1C7
MT100 A3 1E1
MT101 J3 1E1
Q101 M2 1E5
R101 K3 1D1
R102 G4 1E3
R103 G4 1E3
R104 D4 1B3
R105 K1 1B6
R106 K2 1C5
R107 K2 1B5
R108 M2 1B6
R109 E4 1D3
R110 G2 1C4
R111 G1 1C4
R112 G1 1C4
R113 M2 1E4
R114 M3 1E5
R115 M3 1E6
R116 M3 1E6
R117 M2 1D5
R118 M3 1D5
R119 M3 1D6
R120 M3 1D6
R121 M4 1E7
R122 L4 1D6
R123 K2 1B6
U101 G3 1D3
U102 K1 1C5
Grid Reference List

Tait tm8200 Specifications

General

Operating Temperature Range	-30°C to +60°C
IP Rating	IP54
Channel Spacing	12.5 kHz, 25 kHz
Battery Life	N/A (Mobile Radio)
Frequency Range	136-174 MHz, 400-470 MHz
