60 TMAA02-06 Support Kit for Concealed & Dynamic Microphones TM8100/TM8200 Accessories Manual
© Tait Electronics Limited August 2005
Ref. IPN Description
Ref. IPN Description
6.4 PCB Information
6.4.1 TMAA02-06 Parts List (PCB IPN 220-01712-01)
C1 015-26330-08 Cap Cer 0805 330n 5% 10v X7r
C2 015-26330-08 Cap Cer 0805 330n 5% 10v X7r
C3 018-15100-00 Cap 0603 10n 50v X7r +-10%
C4 015-26330-08 Cap Cer 0805 330n 5% 10v X7r
C5 018-16100-00 Cap 0603 100n 16vx7r+-10%
C6 018-16100-00 Cap 0603 100n 16vx7r+-10%
C7 018-16100-00 Cap 0603 100n 16vx7r+-10%
C8 018-16100-00 Cap 0603 100n 16vx7r+-10%
C10 018-16100-00 Cap 0603 100n 16vx7r+-10%
IC1 002-13740-53 IC 74LV4053 Mux/Demux Tssop16
IC2 002-13745-95 IC 74LV595 8BIT SHIFTREG TSSOP
Q1 000-10084-71 Xstr BC847BW NPN SOT323
Q2 000-10085-71 Xstr SMD BC857BW PNP SOT323
Q3 000-10084-62 Xstr BC846S Dual SOT363 NPN
Q4 001-10099-01 Diode BAV99w Dual Ss
R1 038-14220-00 Res 0603 2k2 1/16w +-5%
R2 038-14680-00 Res 0603 6k8 1/16w +-5%
R3 038-14470-00 Res 0603 4k7 1/16w +-5%
R4 038-15470-10 Res 0603 47k 1/16w+-1%
R5 038-14100-10 Res 0603 1k0 1/16w +-1%
R6 038-15330-10 Res 0603 33k 1%
R13 038-15100-10 Res 0603 10k 1/16w +-1%
R14 038-14100-10 Res 0603 1k0 1/16w +-1%
R15 038-14100-10 Res 0603 1k0 1/16w +-1%
R16 038-15470-10 Res 0603 47k 1/16w+-1%
R17 038-15150-10 Res 0603 15K 1% WDS
R18 038-15470-10 Res 0603 47k 1/16w+-1%
R20 036-10000-00 Res M/F SMD 0805 0e 0.125w
S2 240-10002-00 Skt SMD 8w 2x4 Lo-Prof 2mm
S3 240-10001-00 Skt SMD 6w 2x3 Lo-Prof 2mm
220-01712-01 Pcb Dynamic/Covert Mic
P2 240-10004-00 Hdr SMD 8w 2x4 Lo-Prof 2mm
P3 240-10003-00 Hdr SMD 6w 2x3 Lo-Prof 2mm
252-00010-41 Mic Capsule Electret 2.7*6mm
369-01031-00 Rbbr Mic Upper A3M2751 T3K
