134 TOPA-SV-024 Test Unit TM8100/TM8200 Accessories Manual
© Tait Electronics Limited August 2005
Figure 18.2 Test setup
RF COMMS
TEST SET
OSCILLOSCOPE
transmit audio
receive audio /
speaker
connector
power
connector
auxiliary
connector
RF connector
(BNC)
SINAD
AUDIO AUDIO
IN HIOUT
audio
monitor
out (BNC)
RF in/out
(N-TYPE)
(BNC)(BNC)
radio connector
microphone
connector (RJ45)
TEST
PC
(DB15)
serial port
(DB9)
(DB15)
TMAA21-01
TMAA20-03 cable
computer
connector
(RJ12)
AC input
(BNC)
connector
(BNC)
connector
(BNC)
programming
connector (DB9)
TMAA20-02 cable
microphone
connector (RJ45)
TMAA21-01 cable
banana plugs
DC POWER SUPPLY
TOPA-SV-024
T2000-A19
cable
cable
radio with
radio without
user interface
user interface

Tait tm8200 Specifications

General

Operating Temperature Range	-30°C to +60°C
IP Rating	IP54
Channel Spacing	12.5 kHz, 25 kHz
Battery Life	N/A (Mobile Radio)
Frequency Range	136-174 MHz, 400-470 MHz
