TM9400 Specifications Manual Transmitter Specifications 17
© Tait Limited November 2016
3 Transmitter Specifications
This chapter compares the performance of the transmitter in a TM9400
radio with transmitter requirements specified by ETSI and TIA.
Where an ANSI/TIA or ETSI EN 300 113 test method was used to measure
TM9400 performance, this is indicated in parentheses. Where the ETSI test
method EN 300 086-1 was used, no test method is named. Please see also
the footnotes to the tables.
This equipment is compatible with the emissions listed in the following
table.
Notice Some emission designators may not apply in all regions. Not
all models support all emission designators. Contact your regional Tait
office for details.
Notice The TM9400 specifications in this manual are typical perfor-
mance figures that are intended only to provide guidance. They are sub-
ject to change without notice and shall not form part of any contract. To
establish whether the radio meets the regulatory requirements that apply
to you, please contact your regional Tait office.
For important information about how radio performance figures were
derived, see Chapter 1 Introduction.
Emission
Designator Common Name
Modulation
Scheme Operating Modes
11K0F3E analog voice analog FM NB voice
16K0F3E analog voice analog FM WB voice
6K60F2D FFSK data FFSK NB data - 1200 bps
7K80F2D FFSK data FFSK NB data - 2400 bps
9K60F2D FFSK data FFSK WB data - 1200 bps
10K8F2D FFSK data FFSK WB data - 2400 bps
8K10F1E P25 Phase 1 C4FM digital voice
8K10F1D P25 Phase 1 C4FM data/control channel
8K10F7W P25 Phase 1 C4FM digital voice/data/
control channel
8K10F1W P25 Phase 2 H-CPM digital voice /data
