TM9400 Specifications Manual General Specifications 27
© Tait Limited November 2016
User Interface
Control Head
Graphical control head Hand-held control head
Display 4-line graphical
(160x64 pixels)
4-line graphical
(96x62 pixels)
Connectors one 8-way RJ45
(microphone/programming)
one 8-way RJ45
(programming)
Function keys 4 6
Keypad
Function keys
Scroll keys
Selection keys
Volume keys
✔
✔
✔
✔
✔
✔
✔
Alphanumeric keys Via keypad microphone
(if connected)
✔
LED status indicators
Status LED
Function key LED
3
2
3
None
Push-to-talk (PTT) button Via connected microphone On left side
Hookswitch and hanger plate Included with microphone Included with control head
Speaker Internal, 16Ω impedance, >3W None
Microphone Via connected microphone;
covert microphone (internal)
Internal
Volume Rotary control Volume keys
On-off On-off key On-off key
