Tait TM9400

20 Transmitter Specifications TM9400 Specifications Manual
© Tait Limited November 2016
Digital
Parameter
Compliance
limit Measured performance
All bands
a
B1
intentionall
y left blank H5, H7
K5
25W 50W 25W 40W 30/35W
Modulation
FFSK, C4FM, H-CPM
Adjacent channel power ratio (TIA-102)
P25 Phase 1
P25 Phase 2
67dBc
65dBc
67dBc
65dBc
Adjacent channel power ratio (EN 300 113)
60dBc 60dBc n/a
b
intentionally
left blank
60dBc n/a n/a
Transient adjacent channel power ratio (EN 300 113)
50dBc 58dBc n/a
intentionally
left blank
56dBc n/a n/a
Transmitter power attack time (TIA-102)
< 50ms 35ms
intentionally
left blank
43ms 38ms
39ms
Transmitter encoder attack time (TIA-102)
< 100ms 57ms
intentionally
left blank
67ms 62ms
61ms
Throughput delay (TIA-102)
< 125ms 55ms 50ms
intentionally
left blank
55ms
47ms
Modulation fidelity (TIA-102)
<5% 0.5%
intentionally
left blank
0.5% 0.6% 0.6%
a. See "Frequency Bands" on page 6.
b. Not applicable.
