Takagi GS-2600W-AU User Manual

3
FOR THE PLUMBER
PLEASE NOTE this water heater is supplied factory set at 50 °C outlet hot water temperature to comply with
the requirements of AS 3498.2009.
If the water heater is not preset to 50 °C, tempering valve is required.
Please follow all the installaon instrucons in the Installaon and operang instrucons handbook and the
following addional instrucons for the water heater outlet connecon.
1. When connecng the hot water supply to the xtures
in the property a minimum of 1.4 metres of pipe-
work must be used between the outlet of the water
heater and the rst tap and outlet. See Diagram to the
right.
2. The Hot water line should be insulated with Ensolex or
similar pipe insulaon.
3. When the installaon is completed the temperature is
to be tested at the taps to conrm the water tempera-
ture does not exceed the required 50°C seng.
• Total length to
rst tap or outlet
is required to be a
minimum of 1.4
metres from the
outlet connecon of
the water heater.
• Pipe size is nominal
18 mm from hot
water outlet to the
rst tap or outlet.
First tap or outlet
SPECIFICATIONS
MODELS GS-2000W-AU GS-2600W-AU
Gas Input MJ/h 160 195
Inlet Pressure
kPa – Nat. Gas
1.13 min.
2.75 max.
1.13 min.
2.75 max.
Inlet Pressure
kPa - LPG
2.75 min./max. 2.75 min./max.
Water Supply Pressure
kPa
150* min.
1200 max.
150* min.
1200 max.
Height mm 542 542
Depth mm 170 215
Width mm 350 350
Weight kg 15.7 17.2
Gas Connecon mm 20 BSP 20 BSP
Water Connecons 15 BSP 15 BSP
Ignion Electronic Electronic
Electrical Supply V 240 AC 240 AC
NOTES:
* The appliance will operate at reduced performance below 340 kPa.
• For informaon relang to burner test point pressures and injector sizes, refer to the rang plate
located on the right hand side of the cabinet for each model. (Please refer to p. 7.)
• For informaon relang to overall dimensions and connecon points refer to diagrams. (Please refer
to p. 5)
• Before installing in areas over 1500 m above sea level, contact the manufacturer for instrucons.

Takagi GS-2600W-AU Specifications

General

Brand	Takagi
Model	GS-2600W-AU
Category	Water Heater
Language	English
